Seat Diagram Yamaha SRS10/ SW10 Sidewinder B-TX 153 LE 2.25
- Model code
- 8MG1
- Engine Capacity
- 1000
- Year
- 2017
- Sales region
- USA (010)
- Colour
- Deep Purplish Blue Solid E
- Color Variant
- A
- Model
- Sidewinder B-TX 153 LE 2.25
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
8KC-F4710-00-00 SINGLE SEAT ASSYUse for Color DEEP PURPLISH BLUE SOLID E ( DPBSE / 0583 ) |
8KC-F4710-00-00 |
US $464.40 |
||
|
1
|
1
8KC-F4710-10-00 SINGLE SEAT ASSYUse for Color MEDIUM GRAY ( MDGR / 00RG ) |
8KC-F4710-10-00 |
US $416.92 |
||
|
2
|
2
8KC-F470F-00-00 SEAT COVER COMP.Use for Color DEEP PURPLISH BLUE SOLID E ( DPBSE / 0583 ) |
8KC-F470F-00-00 |
US $338.78 |
||
|
2
|
2
8KC-F470F-10-00 SEAT COVER COMP.Use for Color MEDIUM GRAY ( MDGR / 00RG ) |
8KC-F470F-10-00 |
US $354.87 |
||
|
3
|
3
8JR-F4713-00-00 Cushion |
8JR-F4713-00-00 |
US $156.04 |
||
|
4
|
4
8JM-F473U-00-00 StapleUN |
8JM-F473U-00-00 |
US $178.33 |
||
|
5
|
5
8KC-F470E-00-00 BOTTOM PLATE COMP. |
8KC-F470E-00-00 |
US $81.83 |
||
|
6
|
6
8JP-F475H-00-00 Bracket, Seat Lever 1 |
8JP-F475H-00-00 |
US $21.87 |
||
|
7
|
7
8JP-RA523-00-00 Rivet, 14 |
8JP-RA523-00-00 |
US $17.60 |
||
|
8
|
8
8JP-RA270-00-00 Screw, M6X18 |
8JP-RA270-00-00 |
US $6.32 |
