Brake Diagram Yamaha SRX440
- Model code
- SRX440
- Engine Capacity
- 440
- Year
- 1977
- Sales region
- USA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
888-25831-00-00
Disc, Brake
|
888-25831-00-00 |
— | ||
|
2
|
2
8A7-25731-00-00
Body, Caliper 1
|
8A7-25731-00-00 |
— | ||
|
3
|
3
84X-25811-01-00 Pad, Caliper 2 |
84X-25811-01-00 |
from US $25.70 |
||
| replacement | |||||
|
3
|
3
89J-25811-00-00 Pad, Caliper 2 |
89J-25811-00-00 |
from US $29.32 |
||
|
4
|
4
878-25733-00-00 Plate, Back UpUP |
878-25733-00-00 |
US $31 |
||
|
5
|
5
878-25728-00-00 Cam |
878-25728-00-00 |
US $16.06 |
||
|
6
|
6
878-25726-00-00 Lever, Brake |
878-25726-00-00 |
US $13.22 |
||
|
7
|
7
929-01086-00-00
Washer
|
929-01086-00-00 |
— | ||
| replacement | |||||
|
7
|
7
92990-08600-00 Washer, Plate |
92990-08600-00 |
from US $1.34 |
||
|
8
|
8
953-03087-00-00
Nut
|
953-03087-00-00 |
— | ||
| replacement | |||||
|
8
|
8
95380-08700-00 Nut |
95380-08700-00 |
from US $1.42 |
||
|
9
|
9
901-49081-01-00
Screw, Spec''l Shape
|
901-49081-01-00 |
— | ||
|
10
|
10
97012-10060-00 Bolt |
97012-10060-00 |
US $6.13 |
||
| replacement | |||||
|
10
|
10
97017-10060-00 Bolt |
97017-10060-00 |
US $6.13 |
||
|
11
|
11
929-90106-00-00 Washer, Plate |
929-90106-00-00 |
from US $1.07 |
||
|
12
|
12
92990-10100-00 Ybs67-10 Washer, Spring |
92990-10100-00 |
from US $1.34 |
||
|
13
|
13
905-08352-93-00
Spring, Torsion
|
905-08352-93-00 |
— | ||
|
14
|
14
8J7-25848-00-00 Key |
8J7-25848-00-00 |
from US $6.09 |
||
|
15
|
15
8A7-25736-00-00
Hook, Spring
|
8A7-25736-00-00 |
— | ||
|
16
|
16
985-80050-16-00
Screw, Pan Head
|
985-80050-16-00 |
— | ||
| replacement | |||||
|
16
|
16
97885-05016-00 Screw, Pan Head |
97885-05016-00 |
from US $3.12 |
||
|
17
|
17
92990-05100-00 Washer, Spring |
92990-05100-00 |
from US $1.21 |
||
|
18
|
18
929-01056-00-00
Washer
|
929-01056-00-00 |
— | ||
| replacements | |||||
|
18
|
18
92990-05600-00 Washer, Plate |
92990-05600-00 |
from US $1.07 |
||
|
18
|
18
92907-05600-00 Washer, Plate |
92907-05600-00 |
from US $1.07 |
||
