Cover,rear plate & oil pan (ALL (TIMING BELT COVER)) Diagram Mitsubishi GRANDIS
- Year
- 2007 - 2009
- Sales region
- EUR
- Note
- (7PERSONS/DPF),6FM/T LHD
- transmission
- 6FM/T
- grade
- 7PERSONS/DPF
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
02007P
|
02007P
MN980091
COVER,TIMING BELT
|
MN980091 |
— | ||
|
02007Q
|
02007Q
MN980098
COVER,TIMING BELT
|
MN980098 |
— | ||
|
02007S
|
02007S
MN980096
COVER,TIMING BELT
|
MN980096 |
— | ||
|
02012
|
02012
MN980093
COVER,TIMING BELT UNDER
|
MN980093 |
— | ||
|
02019
|
02019
MN980094
PLUG,TIMING BELT COVER
|
MN980094 |
— | ||
|
02965
|
02965
MN980092
CLAMP,TIMING BELT COVER
|
MN980092 |
— | ||
|
02994P
|
02994P
MN980095
BOLT,TIMING BELT COVER
|
MN980095 |
— | ||
|
02994Q
|
02994Q
MN980095
BOLT,TIMING BELT COVER
|
MN980095 |
— | ||
|
02994S
|
02994S
MN980095
BOLT,TIMING BELT COVER
|
MN980095 |
— | ||
|
03110
|
03110
MN980100 BELT,VALVE TIMING |
MN980100 |
US $126.32 |
||
|
03152P
|
03152P
MN980104
PULLEY,TIMING BELT IDLER
|
MN980104 |
— | ||
|
03152Q
|
03152Q
MN980107
PULLEY,TIMING BELT IDLER
|
MN980107 |
— | ||
|
03173
|
03173
MN980101
TENSIONER,TIMING BELT
|
MN980101 |
— | ||
|
03253P
|
03253P
MN980029
STUD,CYLINDER HEAD
|
MN980029 |
— | ||
|
03253Q
|
03253Q
MN980105
STUD,TIMING BELT TRAIN
|
MN980105 |
— | ||
|
03283P
|
03283P
MN980103
NUT,TIMING BELT TRAIN
|
MN980103 |
— | ||
|
03283Q
|
03283Q
MN980106
NUT,TIMING BELT TRAIN
|
MN980106 |
— | ||
|
03285V
|
03285V
MN980108
BOLT,TIMING BELT TRAIN
|
MN980108 |
— | ||
|
11 230
|
Camshaft & valve
11 230
|
||||
|
14 110
|
Water pump
14 110
|
||||
