Manual starter Diagram Yamaha 2 MSH
- Year
- 1988
- Model
- 2
- Year
- 1988
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- Power
- 2
- Sales region
- U.S.A.
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
6A1-15710-00-00 Starter Assy |
6A1-15710-00-00 |
US $88.23 |
||
|
2
|
2
6A1-15711-00-00 Case, Starter |
6A1-15711-00-00 |
US $42.80 |
||
|
3
|
3
6A1-15714-00-00 Drum, Sheave |
6A1-15714-00-00 |
US $12.27 |
||
|
4
|
4
6A1-15767-00-00 Spring |
6A1-15767-00-00 |
US $2.24 |
||
|
5
|
5
6A1-15741-00-00 Pawl, Drive |
6A1-15741-00-00 |
US $8.53 |
||
|
6
|
6
6A1-15713-00-00 Spring, Starter |
6A1-15713-00-00 |
US $15.41 |
||
|
7
|
7
6A1-15717-00-00 Shaft, Starter |
6A1-15717-00-00 |
US $11.07 |
||
| replacement | |||||
|
7
|
7
7RA-15716-00-00 Plate, Drive |
7RA-15716-00-00 |
US $11.07 |
||
|
8
|
8
6A1-15705-00-00 Spring, Drive Pawl |
6A1-15705-00-00 |
US $4.04 |
||
|
9
|
9
970-13060-12-00
Bolt
|
970-13060-12-00 |
— | ||
| replacement | |||||
|
9
|
9
970-80060-12-00 Bolt |
970-80060-12-00 |
from US $1.94 |
||
|
10
|
10
6A1-15755-01-00
Handle, Starter
|
6A1-15755-01-00 |
— | ||
|
11
|
11
6A1-15751-00-00
Rope, Starter (L1300)
|
6A1-15751-00-00 |
— | ||
|
12
|
12
973-13060-16-00
Bolt, Hexagon
|
973-13060-16-00 |
— | ||
| replacements | |||||
|
12
|
12
97095-06016-00 Bolt |
97095-06016-00 |
from US $1.13 |
||
|
12
|
12
97D95-06016-00 Bolt, Hexagon Deep Recess |
97D95-06016-00 |
from US $1.28 |
||
|
13
|
13
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $0.90 |
||
|
14
|
14
6A1-15723-00-94 Pulley, Starter |
6A1-15723-00-94 |
US $16.61 |
||
|
15
|
15
98780-06014-00 Screw Flat Head |
98780-06014-00 |
US $2.84 |
||
