Starter Diagram Yamaha TT600
- Year
- 1984
- Sales region
- USA
- Engine Capacity
- 600
- Model
- TT600
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
34K-15660-00-00
Kick Axle Assembly
|
34K-15660-00-00 |
— | ||
|
2
|
2
34K-15641-00-00
Gear, Kick
|
34K-15641-00-00 |
— | ||
|
3
|
3
90201-20685-00 Washer, Plate |
90201-20685-00 |
from US $1.70 |
||
|
4
|
4
93410-20038-00 Circlip |
93410-20038-00 |
from US $1.94 |
||
|
5
|
5
5Y1-15671-01-00 Wheel, Ratchet (5Y1-15671-00)5Y1-15671-00 |
5Y1-15671-01-00 |
from US $64.10 |
||
|
6
|
6
90501-16107-00 Spring, Compression |
90501-16107-00 |
from US $2.83 |
||
|
7
|
7
90201-155K6-00 Washer, Plain (1Jl) |
90201-155K6-00 |
from US $2.05 |
||
|
8
|
8
99009-15400-00 Circlip(1Ar) |
99009-15400-00 |
from US $1.18 |
||
|
9
|
9
905-08325-29-00
Spring, Torsion
|
905-08325-29-00 |
— | ||
|
10
|
10
90201-15701-00 Washer, Plate (T=1.0) |
90201-15701-00 |
from US $2.08 |
||
|
11
|
11
2NX-15668-00-00 Stopper |
2NX-15668-00-00 |
from US $8.93 |
||
|
12
|
12
2NX-15674-00-00 Guide, Ratchet Wheel |
2NX-15674-00-00 |
from US $10.20 |
||
|
13
|
13
214-15686-00-00 Washer, Lock |
214-15686-00-00 |
from US $2.98 |
||
|
14
|
14
970-11060-16-00
Bolt(3Ap)
|
970-11060-16-00 |
— | ||
| replacements | |||||
|
14
|
14
97095-06016-00 Bolt |
97095-06016-00 |
US $1.52 |
||
|
14
|
14
97014-06016-00 Bolt, Hexagon |
97014-06016-00 |
from US $1.39 |
||
|
14
|
14
97D95-06016-00 Bolt, Hexagon Deep Recess |
97D95-06016-00 |
from US $1.52 |
||
|
15
|
15
248-15668-00-00 Stopper |
248-15668-00-00 |
from US $2.70 |
||
|
16
|
16
931-02201-08-00 Oil Seal (20X30X7-371) |
931-02201-08-00 |
from US $11.18 |
||
| replacement | |||||
|
16
|
16
93102-20814-00 Oil Seal |
93102-20814-00 |
from US $5.67 |
||
|
17
|
17
5Y1-15651-01-00 Gear, Kick Idle |
5Y1-15651-01-00 |
US $121.99 |
||
|
18
|
18
90201-20276-00 Washer, Plate (T=1.0) |
90201-20276-00 |
from US $1.56 |
||
|
19
|
19
99009-20400-00 Circlip |
99009-20400-00 |
from US $1.56 |
||
|
20
|
20
34K-15620-00-00
Kick Crank Assembly
|
34K-15620-00-00 |
— | ||
|
21
|
21
34K-15621-03-00
Boss, Kick Crank
|
34K-15621-03-00 |
— | ||
|
22
|
22
93501-04011-00 Ball |
93501-04011-00 |
from US $1.70 |
||
|
23
|
23
90501-13720-00 Spring, Compression |
90501-13720-00 |
from US $2.55 |
||
|
24
|
24
93210-16314-00 O-Ring |
93210-16314-00 |
from US $1.81 |
||
|
25
|
25
90157-06048-00 Screw, Countersunk |
90157-06048-00 |
from US $2.27 |
||
| replacement | |||||
|
25
|
25
90152-06010-00 Screw, Countersunk (5Y1) |
90152-06010-00 |
from US $2.27 |
||
|
26
|
26
90338-18064-00 Plug |
90338-18064-00 |
from US $3.60 |
||
|
27
|
27
34K-15626-00-00
Stopper
|
34K-15626-00-00 |
— | ||
|
28
|
28
901-79122-44-00
Nut
|
901-79122-44-00 |
— | ||
| replacement | |||||
|
28
|
28
90179-12659-00 Nut |
90179-12659-00 |
from US $1.81 |
||
|
29
|
29
3Y1-1561A-02-00 Lever Dcomp Assembly |
3Y1-1561A-02-00 |
US $73.15 |
||
|
30
|
30
93102-10207-00 Oil Seal10-21-5 HS |
93102-10207-00 |
from US $5.13 |
||
|
31
|
31
90201-105J4-00 Washer, Plate(52H) |
90201-105J4-00 |
from US $2.55 |
||
|
32
|
32
99009-10400-00 Circlip |
99009-10400-00 |
from US $1.50 |
||
|
33
|
33
90508-14524-00
Spring, Torsion
|
90508-14524-00 |
— | ||
|
34
|
34
5Y1-1561G-00-00 Lever, Cable |
5Y1-1561G-00-00 |
from US $14.45 |
||
|
35
|
35
929-01066-00-00
Washer
|
929-01066-00-00 |
— | ||
| replacements | |||||
|
35
|
35
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.18 |
||
|
35
|
35
902-01061-A5-00 Washer, Plate (4H7) |
902-01061-A5-00 |
from US $2.08 |
||
|
35
|
35
92907-06600-00 Washer, Plate |
92907-06600-00 |
from US $1.18 |
||
|
36
|
36
95311-06700-00 Nut |
95311-06700-00 |
from US $1.21 |
||
| replacement | |||||
|
36
|
36
95317-06700-00 Nut(Jn5) |
95317-06700-00 |
from US $1.21 |
||
